Danfoss Pressure Switch Kp1 Manual

Product Details

Pressure Switch, KP1(MANUAL)

Regulation range [bar] Pe: -0.90 - 7.00, Differential [bar]: 0.70, Contact function: SPDT, Reset function: Manual Min, Pressure connection type: Flare, Pressure connection size: 1/4, Pressure Male/Female: Male, Enclosure rating IP: IP30, Max. Working Pressure [bar]: 17.0

BRANDS : DANFOSS

Key Specifications:

SpecificationValue
Gross Weight0.328 Kg
Net Weight0.291 Kg
Volume0.553 Liter
Ambient Temperature Note80°C/176°F for max 120 min
Ambient Temperature Range [°C] (Max/Min)65°C / -25°C
Ambient Temperature Range [°F] (Max/Min)                                                    149°F / -13°F
SpecificationValue
Application NoteNot applicable for liquid line
ApprovalBV, CCC, CE, CMIM, DNV, EAC, GL, LLC CDC EURO-TYSK, LR, LVD, PED, PZH, RINA, RMRS, RoHS China, c UL us UL353, CS C22.2, c UL us UL873, CS C22.2, UKCA
CategoryIV
Contact FunctionSPDT
Contact RatingAC15=10 A, 400 V; AC1=16 A, 400 V; AC3=16 A, 400 V; DC13=12 W, 220 V; LR=112 A, 400 V
Differential [bar]0.7 bar
Differential [psi]10 psi
Electrical ConnectionRubber cable gland
Electrical Connection Size6-14 mm
EN 60947 Electrical PropertiesPollution degree: 3; Rated impulse voltage: 4 kV; Insulation: 400V; Short circuit protection, fuse: 16A
EN 60947 Wiring PropertiesFlex, ferrules: 0.5-1.5 mm²; Flex, no ferrules: 0.7-2.5 mm²; Solid/stranded: 0.75-2.5 mm²
Enclosure Rating IPIP30
Enclosure Rating NEMA (~)1
Fluid Group1
Lubricants CompatibilityOil-free applications
Max. Test Pressure [bar] Pe20 bar
Max. Test Pressure [psig]290 psig
Max. Working Pressure [bar]17 bar
Max. Working Pressure [psig]245 psig
Oil-Free RefrigerantsR134a, R513A, R515B
Packing FormatMulti pack
Pressure Connection Size1/4
Pressure Connection StandardDIN 8906
Pressure Connection TypeFlare
Pressure Male/FemaleMale
Pressure Sensing ElementBellows
Product AccessoriesSwitches accessories
Product DescriptionPressure Switch
Product GroupSwitches and thermostats
Product Name DescriptionPressure Switch
Quantity per Packing Format36 pc
REACH Candidate List SubstancesLead (CAS no. 7439-92-1)
Refrigerants                                                                                                                   R113, R1234yf, R1234yz, R1234ze, R124, R134a, R22, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R454C, R455A, R507A, R513A, R515B
Regulation Range [inHg / bar] Pe (Max/Min)27 inHg - 101 psig / -0.9 bar - 7 bar
Reset FunctionManual Min
SCIP Dossier No.23785618-b379-4da7-a913-ecd40c8fae6d
SCIP Dossier Product NameSolenoid Coils
ServiceableNo
TypeKP1
UL Approval File NameE31024, MH27572
UL Approved RefrigerantsR113, R124, R134a, R22, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R507A, R513A, R515B





Additional Informations
  • Contact us for more information.
    Our sales team will provide you with information and suggestions for selecting the right item.
